Pet Mylar Copper Litz Wire Polyesterimide Stranded

Name: Pet Mylar Copper Litz Wire Polyesterimide Stranded
Brand: Ruiyuan
Price: 1 USD

Pet Mylar Copper Litz Wire Polyesterimide Stranded Manufactures

Brand Name : Ruiyuan

Model Number : 0.1*500

Certification : UL/ISO9001/ISO14001/RoHS/Reach

Place of Origin : China

MOQ : 20 Kilogram/Kilograms

Price : Negotiation

Payment Terms : Negotiation

Supply Ability : Negotiation

Delivery Time : 2-15 days

Packaging Details : Carton

Product name : Mylar litz wire

Thermal Class : 155

Single wire diameter : 0.1mm

No. of strands : 500

Dielectirc strength : Min. 4000V

Insulation material : PET

Contact Now

0.1mm * 500 2UEWF PET Insulation Copper Litz Wire

High Voltage taped litz wire can sustain the voltage over 9KV, that is greatly used in high voltage transformer.Litz wire is a type of specialized multistrand wire or cable used in electronics to carry alternating current (AC) at radio frequencies.

Item/No.	Tech requirement	Test report
Single wire diameter (mm)	0.107-0.125	0.110-0.114
Conductor diameter (mm)	0.10±0.003	0.098-0.10
O.D. (mm)	≤ 3.88	3.05-3.18
Resistance((Ω/m)	≤ 0.004762	0.004408
Dielectric strength( V)	Min. 4000	9400
Pitch (mm)	60±3	60
No. of strands	500	500
Tape overlap %	Min.50	52

Pet Mylar Copper Litz Wire Polyesterimide Stranded
