42 AWG 0.063mm Plain Enamel Copper Wire Magnet Wire For Guitar Pickup 1kg

Name: 42 AWG 0063mm Plain Enamel Copper Wire Magnet Wire For Guitar Pickup 1kg
Brand: Ruiyuan
Price: 1 USD

42 AWG 0.063mm Plain Enamel Copper Wire Magnet Wire For Guitar Pickup 1kg Manufactures

Brand Name : Ruiyuan

Model Number : 0.063mm

Certification : UL/ISO9001/ISO14001/RoHS/Reach

Place of Origin : China

MOQ : 1kgs

Price : Negotiation

Payment Terms : Negotiation

Supply Ability : Negotiation

Delivery Time : 2-15 days

Packaging Details : Carton

Product name : Plain enameled wire for guitar pickup

Diameter : 0.063mm

Color : Dark brown

Resistance : ≤ 5.900 Ω/m

Coating : Plain enamel

Contact Now

42 AWG 0.063mm Plain Enamel Copper Wire Magnet Wire For Guitar Pickup 1kg

Plain Enamel wires are manufactured to single-build dimensional standards.

Was used in vintage pickups from the '50s and '60s and is commonly used today in many of the reissue and custom shop guitar pickups.

  	 			AWG 42 (0.063mm)enameled copper wire
 			Characteristics 			Technical requests 			Test results
 			Sample 1 			Sample 2 			Sample 3
 			Conductor diameter 			0.063±0.002 			0.063 			0.063 			0.063
 			Resistance 			≤ 5.900 Ω/m 			5.478 			5.512  			5.482
 			Breakdown voltage 			≥ 400 V 			1768 			1672  			1763


42 AWG 0.063mm Plain Enamel Copper Wire Magnet Wire For Guitar Pickup 1kg
